Resin, Direct Burial Connector Sealing. Resin is a 2-Part Epoxy Insulating and Encapsulating Resin. For use with 3M Scotchcast O/B, R/Y, Y, R, G, B, 3M 212, 312 or 512 electrical spring connector.

3M™ Scotchcast™ Electrical Resin 3570G-N insulates and offers protection for electrical spring connectors against water, dust, soil and other environmental elements. It is a 2-part, epoxy-based, liquid resin provides excellent flexibility and generates its own heat to cure. This flame-retardant resin is stable in applications at elevated temperatures up to 250 degrees F (121 degrees C). 3M™ Scotchcast™ Electrical Resin 3570G-N provides a tough, multi-purpose, moisture-sealing that comes with a unique, closed mixing pouch for mixing the resin. It is a convenient insulating and encapsulating resin for electrical spring connection. The thermosetting resin does not melt or run after curing. It is suitable for potting and protecting a wide variety of electrical spring connections. This resin is rated for 0 to 600 kV voltage applications. RoHS 2011/65/EU Compliant.

Also known as: 051128591864, 3570G-N, MMM3570GN, Seal Pack
